5G LTE Router with SIM Card Slot, Dual Band Wi-Fi 6 Router, Industrial 802.11ax Router, Up to 1.8Gbps, 3x Gigabit LAN Ports, OFDMA, MU-MIMO

Name: 5G LTE Router with SIM Card Slot, Dual Band Wi-Fi 6 Router, Industrial 802.11ax Router, Up to 1.8Gbps, 3x Gigabit LAN Ports, OFDMA, MU-MIMO
Brand: JTOKEN Official Store
SKU: EX6RM500QAE
Price: 786.57 USD
Availability: InStock

Module RM500Q-AE RM500Q-GL RM502Q-AE RM502Q-GL RM505Q-AE RM510Q-GL

Product variants

$786.57 USD

~~$796.57 USD~~ $786.57 USD

Sold out

Quantity

Overview

JTOKEN 5G industrial routers use high-performance industrial- grade 32-bit communication processors and industrial-grade wireless modules to ensure that the product can run stably for a long time in harsh environments without fear of challenges.

Rugged metal shell, high protection, wide temperature and wide voltage, EMC4 level, can withstand extreme tempera -ture, voltage instability, high electromagnetic radiation,rain and dust attack and other harsh conditions, to ensure continuous communication between remote equipment and monitoring center.
Support NSA and SA networks,compatible with all operators, including TD-LTE/FDD-LTE/TD-SCDMA/WCDMA/EVDO/CDMA1X /GPRS/EDGE and other seven network standards, can flexibly switch operators according to operational needs, more con -venient to select network and traffic are more economical.
Widely used in the M2M industry, such as smart factories, smart medical, smart ports, new media video transmission etc.
In the field of industrial control, it supports VPN function and serial port transparent transmission function, and provides remote upload and download programs and remote connection functions for various brands of PLC.

Key Benefits

880MHz, Memory 128~256MB, Flash 16~32MB;
Adopt high-performance Qualcomm or Zhanrui 5G industrial -grade wireless module, support NSA+SA networking;
Dual serial port design, 1x RS232, 1x RS485, support serial port transparent transmission and serial command;
High-speed network port, 1x Gigabit WAN, 3x Gigabit LAN Support 12-48V DC wide voltage power supply;
Support APN/VPN (PPTP/L2TP/OPENVPN), private network group network frequency lock function; WDT watchdog design, timing restart, network disconnection detection function, to ensure system stability;
Built-in 1.5KV electromagnetic isolation protection for LAN port; Intranet penetration, base station positioning, channel optimization, high speed and low latency, remote control.

Specification

Hardware Performance

CPU	Dual-core four threads 880Mhz frequency;
Memory	On-board SMD DDR3 128MB, Expandable up to 512MB;
Flash	16MB Nor Flash;
WIFI	802.11ax (Wi-Fi 6), Max Data Transmission Rate Up to 1800Mbps, Dual Bands 2.4GHz and 5.8GHz;
Network Supported	Industrial Grade 5G IoT Modules
System Time	NTP, Built-in RTC

Interfaces

WAN	1x WAN Port
LAN	3x LAN Ports(10M/100M/1000M Adaptive MDI MDIX Port)
SIM Card Slot	1x Drawer SIM Card Slot, Supports SIM/UIM Card in 1.8V/3V
USB	Not Supported
Reset	1x Reset Button
Antenna Ports	4x 4G/5G Antenna, Impedance 50 Ohms, SMA Internal Hole Interface; 2x 2.4GHz Wi-Fi Antenna, Impedance 50 Ohms, SMA Internal Hole Interface; 2x 5.8GHz Wi-Fi Antenna, Impedance 50 Ohms, SMA Internal Hole Interface;
Power Connector	1x 2PIN PH3.81 Connector
Console Port	1x Built-in Console Port
Indicators	4x Indicators(1x 5G, 1x SYS, 2x Wi-Fi)

Parameters of Power Supply

Power Supply	External Power Adapter(DC 12V 2A)
Working Voltage	Wide Voltage Input DC 9V~36V
Standby Consumption	300~500mA@12V DC
Working Consumption	500~700mA@12V DC

Working Conditions

Working Temperature	-40°C ~ +85°C (-40°F ~ +185°F)
Storage Temperature	-40°C ~ +85°C (-40°F ~ +185°F)
Working Humidity	5%~95%(Non-condensing)
Device Ventilation	Natual Heat Dissipation, No Noise

Physical Parameters

Chassis	Metal Chassis
Dimensions	155mm(L) x 115mm(W) x 29mm(H) (Antennas Excluded)
Installation	Rail Mounted, Wall Mounted
Weight	N.W.: 0.47kg (Antennas and Accessories Excluded) G.W.: 0.85kg (Antennas and Accessories Included)
Safety and Reliability	Power Inverting Protection, Overvoltage Protection, Overcurrent Protection, Built-in 1.5KV Electromagnetic Isolation Protection of Ethernet Port; Built-in 15KV ESD Protection of RS232/RS485; Built-in 15KV ESD Protection of SIM/UIM Card Interface;
Protection Level	IP45
Certification	CCC, RoHS
MTBF	>100,000 hours

Software Features

Network Access	APN, VPDN Supported
Access Authentication	CHAP/PAP Certification Supported
Network Mode	GSM/GPRS/EDGE, LIMTS/HAPA+/EVDO/TD-SCDMA/TD LTE/FDD LTE/5G NR
LAN Protocol	ARP, Ethernet Supported
WAN Protocol	Static IP, DHCP, PPPoE, PPP Supported
IP Applications	PING, Trace, DHCP Server, DHCP Relay, DHCP Client, DNS Relay, DDNS, Telnet Supported
IP Routing	Routing Supported
NAT	Supported
Industrial Protocol	IEC101/104 Regulations, 212 Environmental Protection Protocol, MQTT, MUDBUS and other industrial protocols are supported

Network Security

Firewall	Full Status Packet Inspection(SPI), Protection Against Denial of Service (DOS) Attacks, Filtering Multicast/Ping Packets, Access Control Lists(ACL), Content URL Filtering, Port Mapping, Virtual IP Mapping, IP-MAC Binding
Data Security	IPsec VPN /L2TP/PPTP/GRE/OPEN VPN/CA Certificate

Reliability

Backup Function	Wired, Dual 5G Three-Way Mutual Backup
Link Online Monitoring	Send heartbeat packet detection, disconnection automatically connected
Embedded Watchdog	Self-test technology, Self-pairing when any failure

Wi-Fi(Integrated)

Protocols	IEEE 802.11 b/g/n/ac/wifi6 ax
Transmission Rate	Up to 1.8Gbps
Security	Open Systems, Shared Key, WPA/WPA2 Authentication, WEP/TKIP/AES Encryption
Working Mode	AP, Client Working Mode
Transmission Distance	100m(Depends on the actual environment)

Intelligent

DTU Integration

TCP/UDP Transparent Transmission Mode;
TCP Server Mode;
Modbus RTU to Modbus TCP Bridge;
DCUDP, DCTCP Mode

Network Management

QOS Management	Bandwidth Limit, IP Speed Limit
Configuration Method	By Telnet, Web, SSH and Console
Upgrade Method	Web Upgrades and FOTA
Log	Local System Logs, Remote Logs, Serial Output Logs, Important Logs Saved when Powered off
SMS	Status Query, Configuration, Restart
Dial-on-Demand	Dial-on-demand, Data Activation, SMS Activation
Network Management	STAR Device Manager Network Management Platform Supported, Batch Management
Simple Network Management	SNMP v1/v2c/v3 and SNMP TRAP
Traffic Management	Traffic Threshold Setting, Traffic Statistics and Traffic Alarms
Alarm	System Restart, LAN Port Online and Offline, Traffic Alarm, SIM Card Failure Alarm and other alarms
Maintenance	Ping, Route Tracing, Internet Speed Testing
Status Query	System Status, Modem Status, Network Connection Status, Routing Status

Operation Band

5G Sub-6	RM500Q-AE	RM502Q-AE	RM505Q-AE	RM500Q-GL	RM502Q-GL	RM510Q-GL
Region/Operator	Global(Except for China)	Global(Except for China)	Global(Except for China)	Global(Except for United States)	Global(Except for United States/China/Japan)	Global
Dimensions(mm)	52.0 x 30.0 x 2.3	52.0 x 30.0 x 2.3	52.0 x 30.0 x 2.3	52.0 x 30.0 x 2.3	52.0 x 30.0 x 2.3	52.0 x 30.0 x 2.3
Weight(g)	8.7	8.7	8.7	8.7	9.0	9.1
Supply Voltage Range	3.135–4.4 V, typical 3.7 V	3.135–4.4 V, typical 3.7 V	3.135–4.4 V, typical 3.7 V	3.135–4.4 V, typical 3.7 V	3.135–4.4 V, typical 3.7 V	3.135–4.4 V, typical 3.7 V
Power Consumption	80 μA @ Power down 4.2 mA @ Sleep 32 mA @ USB 2.0, Idle 52 mA @ USB 3.0, Idle	80 μA @ Power down 4.2 mA @ Sleep 32 mA @ USB 2.0, Idle 52 mA @ USB 3.0, Idle	82 μA @ Power down 4.2 mA @ Sleep 32 mA @ USB 2.0, Idle 52 mA @ USB 3.0, Idle	70 μA @ Power down 4.0 mA @ Sleep 32 mA @ USB 2.0, Idle 52 mA @ USB 3.0, Idle	70 μA @ Power down 4.0 mA @ Sleep 32 mA @ USB 2.0, Idle 52 mA @ USB 3.0, Idle	80 μA @ Power down 4.2 mA @ Sleep 32 mA @ USB 2.0, Idle 54.5 mA @ USB 3.0, Idle
Temperature Range
Operation Temperature	-30°C to +75°C	-30°C to +75°C	-30°C to +75°C	-30°C to +75°C	-30°C to +75°C	-30°C to +75°C
Extended Temperature	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C
Frequency Bands
5G NR-NSA	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n41/n77/n78/n79	n38/n41/n77/n78	n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/ n38/n40/n41/n48*/n66/n71/n77/n78/ n79/n257①/n258①/n260①/n261
5G NR-SA	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48/ n66/n71/n77/n78	n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79
5G MIMO	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48/n66/n77/n78/n79 UL: 2×2 on n41	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48/n66/n77/n78/n79 UL: 2×2 on n41	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48/n66/n77/n78/n79 UL: 2×2 on n41	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48/n66/n77/n78/n79 UL: 2×2 on n41/n77/n78/n79	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48/n66/n77/n78/ UL: 2×2 on n41/n77/n78	DL: 4×4 on n1/n2/n3/n7/n25/n38/n40/ n41/n48*/n66/n77/n78/n79 UL: 2×2 on n41/n257/n258/n260/n261
LTE Category	DL Cat 16 / UL Cat 18	DL Cat 20 / UL Cat 18	DL Cat 16 / UL Cat 18	DL Cat 16 / UL Cat 18	DL Cat 20 / UL Cat 18	DL Cat 20 / UL Cat 18
LTE-FDD	B1/B2/B3/B4/B5/B7/B8/ B12(B17)/B13/B14/B18/B19/ B20/B25/B26/B28/B29/B30/ B32/B66/B71	B1/B2/B3/B4/B5/B7/B8/ B12(B17)/B13/B14/B18/B19/ B20/B25/B26/B28/B29/B30/ B32/B66/B71	B1/B2/B3/B4/B5/B7/B8/ B12(B17)/B13/B14/B18/B19/ B20/B25/B26/B28/B29/B30/ B32/B66/B71	B1/B2/B3/B4/B5/B7/B8/B12/ B13/B14/B17/B18/B19/B20/ B25/B26/B28/B29/B30/B32/ B66/B71	B1/B2/B3/B4/B5/B7/B8/B12/ B13/B14/B17/B18/B19/B20/ B25/B26/B28/B29/B30/B32/ B66/B71	B1/B2/B3/B4/B5/B7/B8/B12/ (B17)/B13/B14/B18/B19/B20/ B25/B26/B28/B29/B30/B32 /B66/B71
LTE-TDD	B34/B38/B39/B40/B41/B42/ B43/B48	B34/B38/B39/B40/B41/B42/ B43/B48	B34/B38/B39/B40/B41/B42/ B43/B48	B34/B38/B39/B40/B41/B42/ B43/B48	B34/B38/B39/B40/B41/B42/ B43/B48	B34/B38/B39/B40/B41/B42/ B43/B48
LAA	B46 (only support 2×2 MIMO)	B46 (only support 2×2 MIMO)	B46 (only support 2×2 MIMO)	B46	B46	B46 (only supported for DL 2 × 2 MIMO)
LTE DL4 x 4 MIMO	B1/B2/B3/B4/B7/B25/ B30/B32/B34/B38/B39/B40/ B41/B42/B43/B48/B66	B1/B2/B3/B4/B7/B25/ B30/B32/B34/B38/B39/B40/ B41/B42/B43/B48/B66	B1/B41	B1/B2/B3/B4/B7/B25/ B30/B32/B34/B38/B39/B40/ B41/B42/B43/B48/B66	B1/B2/B3/B4/B7/B25/ B30/B32/B34/B38/B39/B40/ B41/B42/B43/B48/B66	B1/B2/B3/B4/B7/B25/ B30/B32/B34/B38/B39/B40/ B41/B42/B43/B48/B66
WCDMA	B1/B2/B3/B4/B5/B6/B8/B19	B1/B2/B3/B4/B5/B6/B8/B19	B1/B2/B3/B4/B5/B6/B8/B19	B1/B2/B3/B4/B5/B6/B8/B19	B1/B2/B3/B4/B5/B6/B8/B19	B1/B2/B3/B4/B5/B6/B8/B19
GNSS	GPS/GLONASS/ BeiDou(Compass)/Galileo	GPS/GLONASS/ BeiDou(Compass)/Galileo	GPS/GLONASS/ BeiDou(Compass)/Galileo	GPS/GLONASS/ BeiDou(Compass)/Galileo	GPS/GLONASS/ BeiDou(Compass)/Galileo	GPS/GLONASS/ BeiDou(Compass)/Galileo
Certifications
Regulatory	GCF/ CE/ PTCRB/ FCC/ IC/ NCC/ JATE/ TELEC/ RCM	GCF/ CE/ PTCRB/ FCC/ IC/ JATE/ TELEC/ RCM	GCF / CE/ PTCRB/ FCC/ IC/ JATE/ TELEC/ RCM	GCF/ CE/ SRRC/CCC/ NAL/ KC/ RCM	GCF / CE / PTCRB/ FCC/ IC/ RCM	GCF / CE / PTCRB/ FCC/ IC/ RCM
Carrier	Deutsche Telekom/ Verizon/ AT&T/ T-Mobile/ Telstra	Verizon*/ AT&T/ T-Mobile/ Telstra	Verizon/ AT&T/ T-Mobile/ Telstra*	Deutsche Telekom/ China Telecom/ China Mobile/ China Unicom/ KT/ SKT/ LGU+	TBD	Verizon/ AT&T/ T-Mobile/ Telstra
Others	RoHS/WHQL	RoHS/WHQL	RoHS/WHQL	RoHS/WHQL	RoHS/WHQL	RoHS/WHQL
Data Rate (Max.)①
5G SA Sub-6	DL 2.1 Gbps; UL 450 Mbps	DL 4.2 Gbps; UL 450 Mbps	DL 2.1 Gbps; UL 450 Mbps	DL 2.1 Gbps; UL 900 Mbps	DL 4.2 Gbps; UL 900 Mbps	DL 4.2 Gbps; UL 450 Mbps
5G NSA Sub-6	DL 2.5 Gbps; UL 600/650 Mbps ②	DL 5.0 Gbps; UL 600/650 Mbps ②	DL 2.5 Gbps; UL 600/650 Mbps ②	DL 2.5 Gbps; UL 600/650 Mbps ②	DL 5.0 Gbps; UL 600/650 Mbps ②	DL 5.0 Gbps; UL 600/650 Mbps ③
LTE	DL 1.0 Gbps; UL 200 Mbps	DL 2.0 Gbps; UL 200 Mbps	DL 1.0 Gbps; UL 200 Mbps	DL 1.0 Gbps; UL 200 Mbps	DL 2.0 Gbps; UL 200 Mbps	DL 2.0 Gbps; UL 200 Mbps
WCDMA	DL 42 Mbps; UL 5.76 Mbps	DL 42 Mbps; UL 5.76 Mbps	DL 42 Mbps; UL 5.76 Mbps	DL 42 Mbps; UL 5.76 Mbps	DL 42 Mbps; UL 5.76 Mbps	DL 42 Mbps; UL 5.76 Mbps
Interface
(U)SIM	x 1	x 1	x 2 (Dual SIM Single Standby)	x 2 (Dual SIM Single Standby)	x 2 (Dual SIM Single Standby)	x 1
USB 2.0	x 1	x 1	x 1	x 1	x 1	x 1
USB 3.0/3.1	x 1	x 1	x 1	x 1	x 1	x 1
PCIe 3.0	x 1	x 1	x 1	x 1	x 1	x 1
PCM	x 1	x 1	x 1	x 1	x 1	x 1
Antenna	Cellular: × 3 Cellular + GNSS L1: × 1	Cellular: × 3 Cellular + GNSS L1: × 1	Cellular: × 4 GNSS L1&L5: × 1	Cellular: × 3 Cellular + GNSS L1: × 1	Cellular: × 3 Cellular + GNSS L1: × 1	Sub-6 GHz × 4; mmWave × 8
Voice
Digital Audio & VoLTE	○	○	○	○	-	○
Enhanced Features
eSIM*	○	○	○	○	○	○
DTMF*	●	●	●	●	●	●
DFOTA*	●	●	●	●	●	●
(U)SIM Card Detection	●	●	●	●	●	●
Drivers
USB Serial Driver	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Windows 7/8/8.1/10 Linux 2.6–5.4 Android 4.x/5.x/6.x/7.x/8.x/9.x/10
GNSS Driver	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10
RIL Driver	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10	Android 4.x/5.x/6.x/7.x/8.x/9.x/10
NDIS Driver	Windows 7/8/8.1/10	Windows 7/8/8.1/10	Windows 7/8/8.1/10	Windows 7/8/8.1/10	Windows 7/8/8.1/10	Windows 7/8/8.1/10
MBIM Driver	Windows 10 Linux 3.18–5.4	Windows 10 Linux 3.18–5.4	Windows 10 Linux 3.18–5.4	Windows 10 Linux 3.18–5.4	Windows 10 Linux 3.18–5.4	Windows 10 Linux 3.18–5.4
GobiNet Driver	Linux 2.6–5.4	Linux 2.6–5.4	Linux 2.6–5.4	Linux 2.6–5.4	Linux 2.6–5.4	Linux 2.6–5.4
QMI_WWAN Driver	Linux 3.4–5.4	Linux 3.4–5.4	Linux 3.4–5.4	Linux 3.4–5.4	Linux 3.4–5.4	Linux 3.4–5.4
